P/N CA-1X3-00M1WN-00
La serie View
TIPO DE CAJA Mid Tower
DIMENSIONES (AL x AN x PR) 460x 210 x 395.3 mm
PESO NETO 5.1 kg
PANEL LATERAL 3mm Tempered Glass x 1
Color Black
Material SPCC
SISTEMA DE REFRIGERACIÓN
Front(intake):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 3
BAHÍAS DE EXPANSIÓN
2 x 3.5, 2 x 2.5 or 1 x 3.5, 3 x 2.5
RANURAS DE EXPANSIÓN
7
PLACAS BASE
6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX),
12" x 9.6" (ATX)
PUERTOS E/S
USB 3.0 x 2, HD Audio x 1
FUENTE DE ALIMENTACIÓN
Standard PS2 PSU (optional)
COMPATIBILIDAD VENTILADORES
Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Rear:
1 x 120mm
COMPATIBILIDAD RADIADORES
Front:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 240mm, 1 x 120mm
Rear:
1 x 120mm
LIMITACIONES
CPU cooler max height:
166mm
VGA max length:
300mm (with radiator)
330mm (without radiator)
PSU max length:
190mm (with HDD Cage)
